ASSA ABLOY ACCENTRA Parallel Rigid Application with Hold Open Arms. With 293L Bracket_7325-0252
Open the original PDF document
View PDFYale is a registered trademark of Yale Security Inc., an ASSA ABLOY Group company. Copyright Group company. All rights reserved. Reproduction in whol ® © 2010 Yale Security Inc., an ASSA ABLOY e or in part without the express written permission of Yale Security Inc. is prohibited.
| Opening | Dimension "A" | Dimension "B" | ||
|---|---|---|---|---|
| inches | mm. | inches | mm. | |
| To 120° | 9-5/8 | 244 | 3-3/4 | 95 |
| *Over 120° | 7-1/8 | 181 | 1-1/4 | 32 |
PR2501, PR2511 Door Closer With 293L Bracket for Flush Transoms With or Without 3158 Drop Plate Parallel Rigid Application With Non Hold Open or Hold Open Arms Multi-size Units
100 Yale Ave. Lenoir City,TN 37771-3226 1-800-438-1951
www.yalelocks.com
TEMPLATE NUMBER DATE
07-10 7325-0252
