ASSA ABLOY ACCENTRA PR4400, PR4410 Door Closer Parallel Rigid Non-Hold Open or Hold Open Arm_7344-0253
Open the original PDF document
View PDF
Caution: Door swing may be limited by door, frame, wall or hardware conditions.
Notes:
- 1. Do not scale drawing.
- 2. Left hand door shown.
- 3. Dimensions are in inches (mm).
- 4. Hollow metal doors require channel or box type reinforcement when thru bolt mount is specified.
- 5. Minimum thickness recommended for reinforcements in hollow metal doors and frames: 0.1046" (2.66mm) unless otherwise noted.
- 6. Hold Open Arm closers are not permitted to be used on fire doors.
| Opening | Dim. "A" | Dim. "B" |
|---|---|---|
| To 100° | 8-3/4 (222) | 9-1/4 (235) |
| 100° to 120° | 7-1/4 (184) | 7-3/4 (197) |
| 120° to 150° | 6-1/4 (159) | 6-3/4 (172) |
| 150° to 180° | 5-1/4 (133) | 5-3/4 (146) |
|
4 Holes for Soffit Plate
"B" |
2 to 2-3/4
Reveal (51 to 70) 890 Bracket 293 Soffit Plate |
|---|---|
|
7/16
2 1-1/2 3/8 (50.8) (38) (10) (11.1) 2-3/4 (69.9) 3/4 1-1/4 (31.8) (19) 2 Holes for 890 Bracket 1 (25) |
|
|
2-1/2
1/4 (64) (6) 5/16 1 (7.9) 2-3/8 (25) (60.3) 6-3/4 4 Holes for 488 Drop Plate "A" (171.5) or 4 4-3/4 4 Holes for Closer (101.6) (120.7) 12-3/4 Hinge or Pivot |
891 Spacer Block
890 Bracket 5/8 * (16) 293 Soffit Plate |
| (323.9) |
| Preparation for Fasteners | |||||
|---|---|---|---|---|---|
| Fasteners | To Apply | Door or Frame | Drill Sizes | ||
| Sex nuts and bolts |
Closer or
Drop Plate |
Hollow Metal |
9/32" (7.00mm) thru;
3/8" (9.50mm) door face opposite to closer |
||
|
Aluminum
or Wood |
3/8" (9.50mm) thru: | ||||
|
#14 x 1-1/4" (32mm)
type "A" S.M. Screw |
Soffit Plate | Wood | |||
| Aluminum | 7/32" (5.5mm) | ||||
| 1/4-20 Machine Screw | Metal | drill: #7 (.201") tap: 1/4-20 | |||
|
Thru bolts and
grommet nuts |
Optional | All |
9/32" (7.00mm) thru;
3/8" (9.50mm) dia. x 3/8" (10mm) deep, door face opposite to closer |
||
Copyright © 2004, 2023, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
PR400 or PR1400 Series Door Closers - Sized 2 thru 6 PR4400 or PR4410 Series Door Closers - Multi-Size 1 to 6 Parallel Arm With 890 Bracket and With or Without 488 Drop Plate Non-Hold Open or Hold Open Date: 12/23
Template Number: 7344-0253
Sheet: 1 of 1
