ASSA ABLOY ACCENTRA PA2310BC PA2300 NHO, PA2310 HO Doors Closer Parallel Arm Application Template_80-7323-0101-010
Open the original PDF document
View PDF
| Fastener Chart | |||
|---|---|---|---|
|
lar
Jar |
Fasteners | Door or Frame | Drill Sizes |
| Standard |
1/4-20 Combination
Screw |
Metal | #7(.201"dia.) tap: 1/4-20 |
| Wood | 7/32"(5.54mm.) | ||
| Sex nuts and botts | Hollow Metal |
9/32"(7.00mm.) through
3/8"(9.5mm.) door face opposite to closer |
|
| Optional |
Aluminum or
Wood |
3/8"(9.50mm.) through | |
| ō | Through bolts and grommet nuts | All |
9/32"(7.00mm.) through
3/8"(9.50mm.) dia. × 3/8"(10mm.) deep, door face opposite to closer |
