Yale ® is a registered trademark of Yale Security Inc. Copyright © 2005, 2008, Yale Security Inc. All rights reserved. Reproduction in whole or in part without the express written permission of Yale Security Inc. is prohibited. 7150-8010
|
Use
Fo |
Cylinder Hole |
Thumbturn
Hole |
Rose Post
Hole |
I/S & O/S
Wire Hole |
Keypad
Post Hole |
E8850FL &
E8852FL Post Hole |
Controller
Board Screw Hole |
|
|---|---|---|---|---|---|---|---|---|
| Siz |
1-1/8" Dia.
(29) |
1-1/4" Dia.
(32) |
3/4" Dia.
(19) |
1/2" Dia.
(13) |
1" Dia.
(25) |
1/2" Dia.
(13) |
1/2" Dia.
(13) |
1/4" Dia.
(3) |
| Но | e A | В | С | D | E | G | Н | I |
|
Lock
unction |
Hole Selection
Chart |
||||
|---|---|---|---|---|---|
| Lo | Holes in door | ||||
| Outside | Inside | ||||
| E8850FL | A,D,E,G,H | A,D,E,G,H,I | |||
| E8851FL | A,B,D,E,G | A,D,E,G,I | |||
| E8852FL | A,D,E,G,H | A,C,D,E,G,H,I | |||
| E8853FL | A,B,D,E,G | A,C,D,E,G,I | |||
E8850FL Series eBOSS Mortise Locks Wood and H.M. Door Preparation
Yale<sup>®</sup>
An ASSA ABLOY Group brand
www.yalecommercial.com
7150-8010
05-08
