Installation Instructions

DOOR OUTSIDE FACE

  • 1. Assemble trim. See other side for components and instructions.
  • 2. After marking door inside face for device location (Device Instructions), carry "Vertical Reference Centerline" from inside door face. Follow steps 2a. and 2b. in Figure 2 below.
    • 5. Spot holes and prepare door for trim.6. Mount trim to door. Fasten finger tight only with 2 screws and washers seating on door, as shown in Figure 1,
  • Carry "Horizontal Reference Center- ; line" from inside to outside door face.
  • 7. Cut cylinder tailpiece as shown in Figure 3.

bottom stud.

plus one engaged to long escutcheon

  • Outside face. CAUTION: Office copiers and facsimile machines may change the size of a drawing and make the template inaccurate to use as a door marker. If this is not the original template packed with the trim, use only the dimensions written on the template to locate the holes on the door (do not use the template as a door
    • Seat device so that cylinder tailpiece penetrates cam slot, as shown in Figure 1. Continue as shown in device instructions.

521(F), 531(F) & 532(F) Trim Assembly Instructions

  • 1. Check cylinder components. See "Cylinder Applications" chart. Nonstandard cylinder rings and mounting screws must be supplied with optional cylinders.
  • 2. Assemble cylinder. Insert Cylinder Housing prongs into Escutcheon matching notches. Pass Cylinder tailpiece thru Cylinder Ring and Cylinder Housing slot in cam. Bolt
  • Cylinder seated in Cylinder Ring recess (DO NOT OVERTIGHTEN SCREWS).
  • Check cylinder action. Cylinder key must freely rotate tailpiece when turned in either direction.
  • 4. Assemble Pull (532 ONLY).

Standard: 81-0013-0670-036 Others: As ordered.

Cylinder Ring "L" = (Cylinder "A"-1") Cylinder Ring "L" = Cylinder "A"-CYLINDER MOUNTING SCREWS 60-7000-1235-048 (STD.) 10-1193-1018-048 60-7000-1235-048 34-2311-8738-048 25mm) CYLINDER APPLICATIONS Cylinder Ring CYLINDER RING 1765-.250 (STD.) 1765-.406 1765-.750 1765-.656 1765-.656 1765-.437 1766 1<u>-1/2</u> (38) 5/32 (4) 6-PIN, 1109 (STD.), 5109 YALE CYLINDER 6-PIN, 1709 (CMK) 7-PIN, 1709 (CMK) 6-PIN, U5109 (HS) 7-PIN, U5109 (HS) 7-PIN, 1109, 5109 Rim Cylinder 6-PIN, 1193 (RC) 7-PIN, 1193 (RC) 4

80-8470-0521-000 (6-94)
