ASSA ABLOY ACCENTRA 4600 1-3, 8 Door & Frame Prep WDxHM Template_7046-0002
Open the original PDF document
View PDF
4600 Series Mortise Locks & Electronic Mortise Locks (All Series) 1-3/8" Wood Door and H.M. Frame (ANSI A115.11) Lock and Strike Preparation
Yale Commercial
Yale Commercial Locks and Hardware
www.yalecommercial.com
TEMPLATE NUMBER
7046-0002 5
<u>5-91</u>
