Yale is a registered trademark of Yale Security Inc., an ASSA ABLOY Group company. Copyright Group company. All rights reserved. Reproduction in whol ® © 2010 Yale Security Inc., an ASSA ABLOY e or in part without the express written permission of Yale Security Inc. is prohibited.

2511 Door Closer Top Jamb Application With Hold Open Arm Multi-size Units

100 Yale Ave. Lenoir City,TN 37771-3226 1-800-438-1951

www.yalelocks.com

TEMPLATE NUMBER DATE

07-10 7325-0155
