LIST PRICES EFFECTIVE AUGUST 1, 2015

S E R I E S 1100 ELECTRIC HINGES/PIVOTS

ACSI Series 1100 Electric Hinges/Pivots are designed for doors that require concealed low voltage current transfer, concealed electric monitoring, or concealed low voltage current transfer with monitoring.

Features

• UL listed (UL File BP6073)
• UL Fire Rating on steel and stainless electric hinges (UL File R22305)
• Provide current transfer to electrified mortise or cylindrical locks, exit devices with electric latch retraction, electric strikes (pair of doors), and locks with monitoring or request to exit switches
• UL Rated for 3.5 amp continuous and a 16 amp pulse
• Available in Hager, Stanley, McKinney, Bommer, Rixson, Ives, and more
• Standard weight or heavy weight models
• Steel, brass, or stainless steel hinges
• Available in five knuckle and three knuckle hinges
• All architectural finishes in sizes 4x4 through 6x6
• Hinges/Pivots in stock for same day shipments

ELECTRIC HINGES

Below pricing for hinges supplied by ACSI. Consult the factory for hinges not listed.

Hinge BB1279, FBB179, CB179, TA2714, BB5000, 5BB1 *Std. Wt. Steel	Size 4.0x4.0	Finish 26D 652 10B 640 10A 641 3 632 26 651 10 639 4 633 P 600	Model 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire	List Price $188 200 200 200 200 200 200 200
	4.5x4.0	26D 652 10B 640 10A 641 3 632 26 651 10 639 4 633 P 600	1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire	184 200 200 200 200 200 200 200
	4.5x4.5	26D 652 10B 640 10A 641 3 632 26 651 10 639 4 633 P 600	1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire	166 170 170 170 170 170 170 170
	5.0x4.0	26D 652 10B 640 10A 641 3 632 26 651 10 639 4 633 P 600	1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire	200 214 214 214 214 214 214 214

Hinge BB1279, FBB179, CB179, TA2714, BB5000, 5BB1 *Std. Wt. Steel	Size 5.0x4.5	Finish 26D 652 10B 640 10A 641 3 632 26 651 10 639 4 633 P 600	Model 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire	List Price $192 208 208 208 208 208 208 208
	5.0x5.0	26D 652 10B 640 10A 641 3 632 26 651 10 639 4 633 P 600	1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire	196 208 208 208 208 208 208 208
BB1168, FBB168, CB168, T4A3786, BB5004, 5BB1HW *Heavy Wt. Steel	4.5x4.0	26D 652 10B 640 10A 641 3 632 26 651 10 639 4 633 P 600	1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire	218 234 234 234 234 234 234 234
	4.5x4.5	26D 652 10B 640 10A 641 3 632 26 651 10 639 4 633 P 600	1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire	210 230 230 230 230 230 230 230
	5.0x4.5	26D 652 10B 640 10A 641 3 632 26 651 10 639 4 633 P 600	1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire	220 240 240 240 240 240 240 240
	5.0x5.0	26D 652 10B 640 10A 641 3 632 26 651 10 639 4 633 P 600	1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire	224 240 240 240 240 240 240 240

Hinge BB1191, FBB191, TA2314, BB5001, BB5002, 5BB1 *Std. Wt. Brass or Stainless	Size 4.5x4.0	Finish 26D 626 10B 613 3 605 26 625 10 612 4 606 32 629 32D 630	Model 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire	List Price $216 220 220 220 220 220 274 256
	4.5x4.5	26D 626 10B 613 3 605 26 625 10 612 4 606 32 629 32D 630	1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire	212 220 220 220 220 220 266 248
	5.0x4.5	26D 626 10B 613 3 605 26 625 10 612 4 606 32 629 32D 630	1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire	240 254 254 254 246 246 274 260
	5.0x5.0	26D 626 10B 613 3 605 26 625 10 612 4 606 32 629 32D 630	1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire	240 254 254 254 246 246 282 272
BB1199, FBB199, T4A3386, BB5005, BB5006, 5BB1HW *Heavy Wt. Brass or Stainless	4.5x4.0	26D 626 10B 613 3 605 26 625 10 612 4 606 32 629 32D 630	1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire	258 268 268 268 268 268 308 288
	4.5x4.5	26D 626 10B 613 3 605 26 625 10 612 4 606 32 629 32D 630	1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire	258 268 268 268 268 268 308 280

Hinge BB1199, FBB199, T4A3386, BB5005, BB5006, 5BB1HW *Heavy Wt. Brass or Stainless	Size 5.0x4.5	Finish 26D 626 10B 613 3 605 26 625 10 612 4 606 32 629 32D 630	Model 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire	List Price $268 284 284 284 284 284 328 296
	5.0x5.0	26D 626 10B 613 3 605 26 625 10 612 4 606 32 629 32D 630	1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire	268 284 284 284 284 284 328 304
AB700, TA714, LB8000, 3CB1 *Std. Wt. Steel *3 Knuckle	4.5x4.5	26D 652 10B 640 10A 641 3 632 26 651 10 639 4 633 P 600	1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire	194 208 208 208 208 204 204 204
	5.0x4.5	26D 652 10B 640 10A 641 3 632 26 651 10 639 4 633 P 600	1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire	208 216 216 216 216 212 212 212
	5.0x5.0	26D 652 10B 640 10A 641 3 632 26 651 10 639 4 633 P 600	1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire	208 216 216 216 216 212 212 212
AB750, TA786, LB8004, 3CB1HW *Heavy Wt. Steel *3 Knuckle	4.5x4.5	26D 652 10B 640 10A 641 3 632 26 651 10 639 4 633 P 600	1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire	260 276 276 276 276 276 276 276
	5.0x4.5	26D 652 10B 640 10A 641 3 632 26 651 10 639 4 633 P 600	1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire	276 290 290 290 290 290 290 290

Hinge AB800, TA314, LB8001, LB8002, 3CB1 *Std. Wt. Brass or Stainless *3 Knuckle	Size 4.5x4.5	Finish 26D 626 10B 613 3 605 26 625 10 612 32 629 32D 630	Model 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire	List Price $256 308 308 308 256 290 290
	5.0x4.5	26D 626 10B 613 3 605 26 625 10 612 32 629 32D 630	1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire	280 328 328 328 280 320 320
	5.0x5.0	26D 626 10B 613 3 605 26 625 10 612 32 629 32D 630	1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire	280 298 298 298 280 320 320
AB850, TA386, LB8005, LB8006, 3CB1HW *Heavy Wt. Brass or Stainless *3 Knuckle	4.5x4.5	26D 626 10B 613 3 605 26 625 10 612 32 629 32D 630	1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire	286 338 338 338 286 332 332
	5.0x4.5	26D 626 10B 613 3 605 26 625 10 612 32 629 32D 630	1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire	318 368 368 368 318 354 354
	5.0x5.0	26D 626 10B 613 3 605 26 625 10 612 32 629 32D 630	1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire 1104-4 wire	318 368 368 368 318 354 354

ELECTRIC HINGE OPTIONS (ADD TO 1104 LIST PRICE)

Model	Hinge Option Description	List Price
1102	Concealed electric through-wire (2 wire, 22 ga)	$40
1106	Concealed electric through-wire (6 wire)	52
1108	Concealed electric through-wire (8 wire)	62
1100-10	Concealed electric through-wire (10 wire)	116
1100-12	Concealed electric through-wire (12 wire)	124
1182	Concealed electric through-wire (2 wire, 18 ga)	50
1182x4	Concealed electric through-wire (2 wire, 18 ga x 4 wire, 28 ga)	96
1182x6	Concealed electric through-wire (2 wire, 18 ga x 6 wire, 28 ga)	116
1110	Concealed electric monitor	20
1114	Concealed electric through-wire + monitor (4 wire)	166
1116	Concealed electric through-wire + monitor (6 wire)	186
1118	Concealed electric through-wire + monitor (8 wire)	210
1120	Concealed air transfer	60
ES	Exposed electric switch (1 switch)	Consult Factory
	Radius corner hinges	15
	Long wire leads (4 wire)	$2/Foot net
	Long wire leads (6 wire)	3/Foot net
	Long wire leads (8 wire)	4/Foot net
302-03-03	7" Hinge mortar guard	$36
LC-4	Lynx Connector (ASSA Connector)	34
LC-6	Lynx Connector (ASSA Connector)	48
LC-8	Lynx Connector (ASSA Connector)	60
LC-10	Lynx Connector (ASSA Connector)	74
LC-12	Lynx Connector (ASSA Connector)	84

Note: Consult factory for Swing Clear, Wide Throw, Half Mortise, Half Surface, Raised Barrel, Hospital Tips, and all other hinges not listed for price and availability.

ELECTRIC PIVOTS

Pivot	Finish	Model	List Price
M19	26D, 26, 10B, 3, 10, 4	1102/1104	$400
M19	26D, 26, 10B, 3, 10, 4	1110	410
M19	26D, 26, 10B, 3, 10, 4	1108	420

ELECTRIC HINGES/PIVOTS MODIFICATIONS

Below pricing for modifications to distributor supplied hinges.

Model	Hinge Modification Description	List Price
1102	Concealed electric through-wire (2 wire, 22 ga)	$204
1104	Concealed electric through-wire (4 wire)	164
1106	Concealed electric through-wire (6 wire)	216
1108	Concealed electric through-wire (8 wire)	224
1100-10	Concealed electric through-wire (10 wire)	258
1100-12	Concealed electric through-wire (12 wire)	264
1182	Concealed electric through-wire (2 wire, 18 ga)	210
1182x4	Concealed electric through-wire (2 wire, 18 ga x 4 wire, 28 ga)	260
1182x6	Concealed electric through-wire (2 wire, 18 ga x 6 wire, 28 ga)	280
1110	Concealed electric monitor	164
1114	Concealed electric through-wire and monitor (4 wire)	326
1116	Concealed electric through-wire and monitor (6 wire)	364
1118	Concealed electric through-wire and monitor (8 wire)	390
1120	Air transfer	200

ELECTRIC HINGES/PIVOTS MODIFICATION COMPARISON CHART

ACSI	STANLEY	HAGER	IVES	McKINNEY
1104	CE-54	ETW-4	TW4	CC-4
1106	CE-56	ETW-6	TW6	CC-6
1108	CE-58	ETW-8	TW8	CC-8
1110	CS	EMN	MON	CS
1114	CECS-54	ETM-4	TW4M	CSCC-4
1116	CECS-56	ETM-6	TW6M	CSCC-6
1118	CECS-58	ETM-8	TW8M	CSCC-8

HOW TO ORDER (EXAMPLE)

Hinge/Part Description Modification FBB179 4.5x4.5 26D 1104 BB1279 5.0x4.5 10B 1108 M19-US26 LH 1110

LYNX CONNECTOR CROSS REFERENCE

ACSI Part Number	ASSA Part Number		Harness Description
LC-D003	QC-C003P	QC-C003	3" 12-WIRE 2-MALE Harness Assembly
LC-D006	QC-C006P	QC-C006	6" 12-WIRE 2-MALE Harness Assembly
LC-D012	QC-C012P	QC-C012	12" 12-WIRE 2-MALE Harness Assembly
LC-D200	QC-C200P	QC-C200	26" 12-WIRE 2-MALE Harness Assembly
LC-D206	QC-C206P	QC-C206	32" 12-WIRE 2-MALE Harness Assembly
LC-D300	QC-C300P	QC-C300	38" 12-WIRE 2-MALE Harness Assembly
LC-D306	QC-C306P	QC-C306	44" 12-WIRE 2-MALE Harness Assembly
LC-D400	QC-C400P	QC-C400	50" 12-WIRE 2-MALE Harness Assembly
LC-D1500	QC-C1500P	QC-C1500	15' 2" 12-WIRE 2-MALE Harness Assembly

Note: For pricing see Series 1500 Electric Lock, p 18.
