Aluminum Geared Hinge

Standard Features:

• Full Surface, Heavy Duty
• 1/16" Door Inset
• For narrow-faced frames
• 48" Door Width Maximum
• 450 lbs. Door Weight Maximum
• Frame Side Leaf Countersunk for Stainless Steel Flat Head Screws

Fasteners:

• Frame: 12-24 x ⅝" Phillips FH Undercut Self-Drilling, Machine Screws, Stainless Steel
• Door: ¼" 20" X 1¼" x ⅜" dia. sex bolts & ¼" - 20" x 1¼" Phillips head shoulder screws.

Standard Lengths:

• 83", 95" and 120"

Finishes:

• Clear Anodized Stocked (48 hour shipping)
• Dark Bronze Anodized Stocked (48 hour shipping)
• Black Anodized Stocked (48 hour shipping)
• Champagne
• Light Bronze
• Medium Bronze
• * Custom Powder Coating Available

Fire Rating:

• Approved for use on metal swinging type fire doors rated up to and including 90 minutes (Specify " FR " option for 3 hour rating)
• Approved for use on wood swinging type fire doors rated up to and including 60 minutes (Specify " FR " option for 90 minutes rating)
