A508-A509 Clearance Chart

A508-A509 CLEARANCE LAYOUT-00.DWG A508-A509 CLEARANCE LAYOUT SINGLE RABBIT FRAME, RIGHT HAND SHOWN A508 (DOUBLE ACTING STAINLESS STEEL HINGE) A509 (RESCUE STOP) NOTCH CUTOUT REQUIRED FOR 2-3/4" BACKSET 1/8" MIN. CLEARANCE FOR SQUARE OR BEVELED DOORS ISSUED 05-19-20 A508-A509 CLEARANCE LAYOUT PAGE 1 OF 1 c 2020 ABH Mfg., Inc printed inUSA www.abhmfg.com E-mail: abhinfo@abhmfg.com Architectural Builders Hardware Mfg., Inc. 1222 Ardmore Ave., Itasca, IL 60143 630.875.9900; FAX 800.9FAXABH (932.9224) A509 1 7/8 MAX. JAMB 5/8 7/8 1 3/4 3/4 1 5/8 ³ 1 1/2 MIN. JAMB 5/8 A508 STOP ROTATION 5/8 CASEOPENING FRAME, RIGHT HAND SHOWN A508 (DOUBLE ACTING STAINLESS STEEL HINGE) A509 (RESCUE STOP) NOTCH CUTOUT REQUIRED FOR 2-3/4" BACKSET 1/8" MIN. CLEARANCE FOR SQUARE OR BEVELED DOORS 1 7/8 MAX. JAMB 5/8 7/8 1 3/4 3/4 1 1/2 MIN. JAMB 5/8 STOP ROTATION VARIES ON FRAME WIDTH A509 CENTERLINE WILL VARY ON DOOR THICKNESS WILL VARY ON FRAME WIDTH CENTERLINE WILL VARY ON DOOR THICKNESS 1 5/8 ³ A508
