8700 Series Mortise Lock Bolt Position Dimensions_7086-0000

Open the original PDF document

View PDF

Printed in U.S.A. 7086-0000

Yale Mortise Locks Bolt Position Dimensions Mechanical / Electrical / Exit Device

Yale Commercial Locks and Hardware www.yalecommercial.com

www.yaiecommerciai.com

TEMPLATE NUMBER

7086-0000 DATE

10-02
