Overhead Holders & Stops

8000 Series Surface Mount, Heavy Duty

Standard Features

• Surface mount
• Heavy duty
• • NY SCA approved
• Stop and hold-open functions available
• Single acting doors only
• Non-handed
• weight doors
• Standard installation from 85° to 110° of opening (5° increments)
• Shock absorbing spring provides 3° to 5° cushion before dead-stop
• Standard fasteners supplied with sex bolts for 1-¾" to 2-¼" thick door (see options for other door thicknesses)
• UL Listed as Miscellaneous Fire Door Accessories for use on rated up to 3 hours (stop function only)
• Average weight per unit = 5 lbs.

Door Frame Opening		Model Number
Hinges or Offset Pivots	Center Hung	Hold Open	Stop
27" - 32-	29-½" - 34-	8010	8020
32-½" - 38-	35" - 41-	8011	8021
38-¾" - 42-	41-½" - 44-	8012	8022
42-½" - 54"	45" - 56"	8013	8023
ANSI Code		C03511	C03541

Options Available

(see page B-5 for details)

• • THICK – Fasteners for doors other than 1-¾" to 2 -¼" thick – Specify door thickness
• • SEC – Security fasteners
• • AJB 90541 Angle jamb bracket
• • LL – For lead-lined door applications
• • LS – Less shock-absorbing spring for special applications
• • HD – Extra heavy duty application – Two additional sex bolts and fasteners provided for door
• • SPECIAL – Contact ABH if the dimensions, hardware or is shown on the template or if additional hardware is being used at the top of the door. A custom template and/or unit may be required.
• If using a closer, please go to our website and reference "ABH Overhead Holder & Stop Compatibility Chart" to

Material

• Stainless steel is the standard base material for arm, channel

Specify When Ordering

• Model Number
• Finish
• Option(s), if applicable
