Overhead Holders & Stops

7000 Series Surface Mount, Heavy Duty

Standard Features

• Surface mount
• Heavy duty
• Stop and hold-open functions available
• Single acting doors only
• Non-handed
• weight doors
• Standard installation from 85° to 110° of opening (5° increments)
• Shock absorbing spring provides 3° to 5° cushion before dead-stop
• Standard fasteners supplied with sex bolts for 1-¾" to 2" thick door (see options for other door thicknesses)
• UL Listed as Miscellaneous Fire Door Accessories for use on rated up to 3 hours (stop function only)
• Average weight per unit = 3 lbs.

Door Frame Opening		Model Number
Hinges or Offset Pivots	Center Hung	Hold Open	Stop
23" - 28-	24" - 31-	7010	7020
29" - 34-	32" - 38-	7011	7021
35" - 40-	38-½" - 44-	7012	7022
41" - 46-	44-¼" - 50-	7013	7023
47" - 54"	50-¼" - 60"	7014	7024
ANSI Code		C08511	C08541

Options Available

(see page B-5 for details)

• • THICK – Fasteners for doors other than 1-¾" to 2" thick - Specify door thickness
• • SEC – Security fasteners
• • AJB 70377 Angle jamb bracket for pull side mount or push side
• • LL – For lead-lined door applications
• • N – All stainless steel (non-ferrous) components for wet environments to prevent corrosion
• • SPECIAL – Contact ABH if the dimensions, hardware or is shown on the template or if additional hardware is being used at the top of the door. A custom template and/or unit may be required.
• If using a closer, please go to our website and reference "ABH Overhead Holder & Stop Compatibility Chart" to

Material

• Stainless steel is the standard base material for jamb bracket (bar is cold rolled steel, cad plated).

Specify When Ordering

• Model Number
• Finish
• Option(s), if applicable
