Application

IDC key switch assemblies provide an economical method of providing authorized control for a variety of applications. A choice of several contact configurations ensure compatibility with virtually any system.

• Access Control
• Automatic Gate Operation
• Roll Up Door Operation
• Alarm Shunt
• Alarm Reset
• Machine Operation

New Construction or Retrofit

IDC key switch assemblies are compatible with U.S. standard, 1.125" and 1.25" mortise key cylinders and interchangeable core cylinders (not included). Compatibility with a new or existing facility mechanical key system is maintained. Standard switch assemblies are single gang box mounted. Assemblies equipped with narrow faceplates are mounted directly to the door frame.

Functions

• Momentary
• Timed Actuation (1-60 seconds)
• Alternate Action (On-Off)
• Tamper resistant, recessed cylinder (all except 700N)
• Tamper resistant spanner screws
• Heavy duty all steel assembly
• Stainless steel faceplates of 20 gauge or 0.25" thickness of aluminum
• Large actuator for positive and consistent activation
• 6 Amp @ 30 VDC
• 7", 22 gauge wire leads
• Compatible with 1.125" or 1.25" mortise cylinder (not included)

700/800 SERIES

KEY SWITCHES

700 700N

• Spanner security screws and tool
• 20 Gauge stainless steel
• Optional plated finishes

700 Single gang, wall mounted, anti-tamper recessed

key cylinder

700N Narrow 1.75" wide, frame mounted

800 800N

• 0.25" Aluminum faceplate
• Spanner security screws and tool
• Anti-tamper plugs for mounting screws
• Anti-tamper recessed key cylinder

800 Single gang, wall mounted

800N Narrow, 1.75" wide frame mounted

Four mounting screws provide increased integrity

700T

• Two Gang
• 4 Security screws
• 20 Gauge stainless steel

Two gang faceplate provides for the use of a larger junction box to accommodate time delays, audible annunciation and increased wiring.

International Door Closers, Inc.

West: 800-544-4422 • East: 800-225-6737

COPYRIGHT 2018 INTERNATIONAL DOOR CLOSERS, INC www.intldoorclosers.com

702

Model		Operation	Applications
701 701N 701T	801AL 801ALN	Alternate action SPDT Turning the key left or right actuates and latches the contact. Contact position is maintained until the key is inserted and turned again.	Circuit on - off Access control bypass Machine operation
702 702N 702T	802AL 802ALN	Momentary SPDT Turning the key left or right momentarily actuates the contact.	Momentary access Timer activation Alarm reset
704	804AL	Momentary SPDT plus 10TD Electronic Mini Timer SPDT 2Amp @ 30VDC, adjustable 1 - 60 seconds Turning the key left or right activates an electronically timed contact for 1 - 60 seconds	Timed access Timed alarm shunt
705	805AL		Control two circuits simultaneously
705N 705T	805ALN	Alternate action DPDT Turning the key left or right actuates and latches the contact. Contact position is maintained until the key is inserted and turned again	Access and alarm bypass Lock and magnetic door holder control
706	806AL
706N	806ALN	Momentary DPDT Turning the key left or right momentarily	Control two circuits simultaneously
706T		actuates the contacts
707	807AL	#1 Momentary SPDT. Turning the key left momentarily actuates
707N	807ALN	contact #1. #2 Momentary SPDT. Turning the key right momentarily actuates	Control two circuits independently
707T		contact #2
708	808AL	#1 Momentary SPDT. Turning the key in one direction momentarily
708N	808ALN	actuates contact #1 #2 Alternate action SPDT. Turning the key in opposite direction	Control two circuits independently Momentary access and sustained bypass
70011	OUGALIN	actuates and latches contact #2 until the key is inserted and t	of a door
708T		urned again
709	809AL	#1 Alternate action SPDT. Turning the key left actuates and latches	Control two circuits independently Propose with single station #4
709N	809ALN	contact #1 #2 Alternate Action SPDT. Turning the key right actuates and latches	Bypass with single station #1 Bypass with all stations #2
709T		contact #2
710T		#1 Momentary SPDT plus 10TD Electronic Mini Timer, SPDT 2Amp, 1-60 second. Turning the key in one direction activates an electronically timed contact for 1 - 60 seconds. #2 Alternate action SPDT. Turning the key in opposite direction actuates and latches contact #2	Control two circuits independently Timed access and sustained bypass of a door Timed alarm shunt (REX) and sustained alarm shunt
711	811AL	#1 Momentary DPDT. Turning the key left momentarily actuates contact #1. #2 Momentary DPDT. Turning the key right momentarily actuates contact #2.	Control two pairs of circuits independently
711N	811ALN
711T
712	812AL	#1 Momentary DPDT. Turning the key in one direction momentarily	Control two pairs of circuits independently
712N	812ALN	actuates contact #1 #2 Alternate action DPDT. Turning the key opposite direction actuates	Activate a time delay, REX input or alarm shunt with #1
712T		and latches contact #2 until the key is inserted and turned again.	Access control and alarm bypass with #2
713	813AL	#1 Alternate action DPDT. Turning the key left actuates and latches
713N	813ALN	contact #1. #2 alternate action DPDT. Turning the key right actuates and latches	Control two pairs of circuits independently
713T		contact #2
