628-2-Switch Bollard Specification Sheet

	TECHNICAL SPECIFICATIONS

Dimensions (with cap attached)	41 ½"H x 6 ¼" W x 4 ¼"D
Material Post	Carbon Steel (Inside and Out)
Cap	UV-Resistant ABS Plastic
Mounting Bracket	Stainless Steel
Pushplate Options	4 ½" Square Push plate 4 ¾" Square Push plate 4 ¾" Square Panther Push plate Dual Vestibule Push plate 4 ½" Round Push plate Low Profile Push plates
Weight	35 lbs (16 kilos)
Colors	Black, Bronze, Silver
Mounting Hardware	Anchors, Washers and Nuts (Included)

Specifications are subject to change without prior notice.

DISCLAIMER This document as well as all other enclosed documents (quotation / specification / other) are provided «as is» without warranties of any kind, either expressed or implied, including but not limited to the implied warranties of merchantability, fitness for a particular purpose, or non-infringement. / Information is supplied upon the condition that the persons receiving it will make their own determination as to its suitability for their purposes prior to use. In no event will IDC be responsible for damages of any nature whatsoever resulting from the use of or reliance upon information from this document or the products to which the information refers. / IDC has the right without liability to change descriptions and specifications at any time. / Prices, shipping and availability are subject to change without prior notice.

West: 800-544-4422 • East: 800-225-6737
