Jamb Style 425 SERIES PUSH PLATE SWITCHES

PRODUCT DESCRIPTION

he 425 Series jamb style switches are designed to provide reliable, unobtrusive activation of any automatic door.

The 425 Series features 1 11/16" x 4 1/2" face plates in either stainless steel or blue powder coated aluminum. They include self-sticking mylar labels for customizing the face plate.

Mount the 425 Series directly onto the jamb of an automatic door (fits a 1 3/4" frame) or in MS SEDCO's optional surface mount box.

Each unit is built utilizing heavy gauge metals, aircraft quality rivets and screws, durable finishes and the most reliable microswitch in the industry.

American National Standards Institute (ANSI) - Building Hardware Manufacturers Association (BHMA) - ANSI/ BHMA A156.10 & A156.19.

#425B-BLK (Blue Powder Coat Face Plate, Black Button Switch)

#425SS-BLK (Stainless Steel Face Plate, Black Button Switch)

#425B-RED (Blue Powder Coat Face Plate, Red Button Switch)

#425SS-RED (Stainless Steel Face Plate, Red Button Switch)

1½" Self-Sticking Mylar Face Plate Decal (Blue Background/White Legend)

TECHNICAL DATA

1 11/16" x 4 1/2" Face Platesin Stainless Steel or Blue Powder Coated Aluminum
1" Diameter Button Switch(Black or Red)
UL Listed Micro Switch, SPDT,Mom., 15 Amp @ 125V AC
Fits 1 3/4" Frame or MS SEDCO#1106 Surface Mounting Box
Includes Self-Sticking Mylar Face Plate Labels
