40DBB Deadbolts Specification Sheet

DEADBOLTS HEAVY-DUTY DEADBOLTS

40DBB SERIES • ANSI GRADE 1

A Heavy Duty commercial quality deadbolt that provides a maximum deterrent to forced entry. The cylinder recesses into the door to resist blows attempting to move the lock.

• 2-1/2" dia solid steel one-piece design security ring insert. exceeds ANSI Grade 1 security against hammer and crowbar prying attacks.
• 1" (25mm) deadbolt with hardened steel core exceeds ANSI Grade 1 Security against kick-in and saw attacks.
• High precision pick resistant solid brass 6 pin tumbler plug "C". Brass key Meets ANSI Grade 1 Security to prevent key cylinder from being knocked out.
• Drive in deadbolt Designed to be installed on metal door conveniently. Only one hole is needed on door edge.
• ADA Ergonomic thumb turn.
• Extra thick steel mounting plate
• Sturdy, all steel latch case and mechanism.

PB - Polished Brass

SB - Satin Brass

AB - Antique Brass

AC - Antique Copper

SN - Satin Nickel

SC - Satin Chrome

CR - Polished Chrome

ORB - Oil Rubbed Bronze

TB - Black Nickel

AN - Antique Nickel

PVD - Lifetime Finish

5 or 6 Pin two-piece cylinder

5 or 6 Pin one-piece cylinder

Drive in deadbolt

Inside Rose Assembly

SINGLE CYLINDER 40DBBT

Sturdy 2-1/2" dia molden steel security ring insert

40DBKTS6 SINGLE CYLINDER

40DBKKS6 DOUBLE CYLINDER

Door Prep:	Cross bore 2-1/8" , Edge bore 1" Latch face 1"x2-1/4" .
Backset:	2-3/4" standard, 2-3/8" optional.
Door Thickness:	Adjustable 1-3/8" 2".
Cylinder:	5-Pin or 6-Pin removable core. Schlage "C " keyway or Kwikset and other options available.
Face plates:	1"x2-1/4" square corner standard. Round corner and other options available.
Strikes:	1-1/8"x2-3/4" square corner standard. Round corner and other options available.
Bolt:	1" throw. Nickel plated.
ANSI/BHMA:	A156.5 Grade 1.
