3935 ASA Strike – Wood Frame Template – T-LS00166-Rev04
Open the original PDF document
View PDF3935 ASA STRIKE WOOD JAMB PREP TEMPLATE
NOTES;
1. DIMENSION "Y" IS A FUNCTION OF DOOR THICKNESS.
2. STRIKE LOCATION MUST BE CHANGED RELATIVE TO THICKNESS OF DOOR SILENCER OR WEATHERSTRIPPING WHEN USED.
DIMENSIONS IN [ ] ARE IN MILLIMETERS
DRAWING NO: T-LS00166 REV: 04 SHEET 1 OF 1 HAGER COMPANIES 139 Victor Street, St. Louis, MO 63104 - (800) 325-9995 - Fax (800) 782-0149 TEMPLATE NO:
