Overhead Holders & Stops

3400 Series Surface Mount, Medium Duty

Standard Features

• Surface mount
• Medium duty
• Side jamb mount for doors that do not extend to frame header
• Ideal for dressing room and washroom stall doors with frames
• Stop, hold-open and friction functions available
• Single acting doors only
• Non-handed
• Standard installation from 90° to 100° of opening (5° increments)
• Shock absorbing spring provides 3° to 5° cushion before dead-stop
• Standard fasteners supplied with sex bolts for 1-¾" to 1-⅞" thick door (see options for other door thicknesses)
• Average weight per unit = 3 lbs.

Options Available

(see page B-5 for details)

• • THICK Fasteners for doors other than 1-¾" to 1-⅞" thick - Specify door thickness
• • SEC Security fasteners
• • LL For lead-lined door applications
• • LS Less shock-absorbing spring for special applications
• • N All stainless steel (non-ferrous) components for wet environments to prevent corrosion
• • HC Hold closed
• • SPECIAL Contact ABH if the dimensions, hardware or is shown on the template or if additional hardware is being used at the top of the door. A custom template and/or unit may be required.
• If using a closer, please go to our website and reference "ABH Overhead Holder & Stop Compatibility Chart" to

Material

• Stainless steel is the standard base material for arm, channel

Door Frame Opening	Model Number
Hinges	Hold Open	Stop	Friction
24" - 36"	3414	3424	3434

Specify When Ordering

• Model Number
• Finish
• Option(s), if applicable
