Overhead Holders & Stops

Surface mount
Medium duty
Stop, hold-open and friction functions available
Single acting doors only
Non-handed
For interior use on moderate traffic and medium weight doors
Degree of opening is field-adjustable after installation from 85° to 110° (5° increments)
Shock absorbing spring provides 3° to 5° cushion before dead-stop
Standard fasteners supplied with sex bolts for 1-¾" to 1-%" thick door (see options for other door thicknesses)
UL Listed as Miscellaneous Fire Door Accessories for use on wood fire doors rated up to 90 minutes and metal fire doors rated up to 3 hours (stop function only)
Average weight per unit = 3 lbs.

(see page B-5 for details)

THICK Fasteners for doors other than 1-34" to 1-78" thick - Specify door thickness
SEC Security fasteners
AJB 44443 Angle Jamb Bracket for pull side mount or push side flush mount
LL For lead-lined door applications
CL For use with cam lift hinges
LS Less shock-absorbing spring for special applications
N All stainless steel (non-ferrous) components for wet environments to prevent corrosion
T Jamb bracket is replaced with a threaded pivot screw and nylon washer
HC Hold closed
SPECIAL Contact ABH if the dimensions, hardware, or specifications differ from what is shown on the template or if additional hardware is being used at the top of the door. A custom application and/or unit may be required.
If using a closer, please go to our website and reference "ABH Overhead Holder & Stop Compatibility Chart" to determine possible conflict.

• Stainless steel is the standard base material for arm, channel and jamb bracket for all finishes.
