18158-FE Door Edge Pull – Template

18158-FE DOOR EDGE PULL Optional Extended Standard Widths*(CHECK ONE): 18158-FE-150 1-1/2" Wide 18158-FE-200 2" Wide 18158-FE-250 2-1/2" Wide 18158-FE-300 3" Wide 18158-FE-350 3-1/2" Wide CUSTOM-Please Provide: Door Thickness Panel Thickness 5/16" *For Doors with optional cladding, mirrors or to cover the thickness of the door DOOR PANEL DOOR THICKNESS TOP VIEW $\backslash bigcirc$ $\backslash frac\{1\}\{4\}$ 5/16" 4-1/4" (2.1250 FRONT VIEW EXTENDED SIDE VIEW INSTALLS WITH #8 WOOD SCREWS 18158-FE-02.DWG

www.abhmfg.com E-mail: abhinfo@abhmfg.com Architectural Builders Hardware Mfg., Inc. 1222 Ardmore Ave., Itasca, IL 60143 630.875.9900; FAX 800.9FAXABH (932.9224)
