1804 Pipe Stop & Holder – Template

DOOR STOP / HOLD OPEN WARNING: HINGE SHOWN FOR EXAMPLE IF POSSIBLE INSTALL WELL OUT OF FOOT TRAFFIC SUPPLIED WITH FOUR #8x1-1/4 PHILLIPS LOCK EDGE FLAT HEAD SHEET OF DOOR METAL SCREWS INSTALL DOOR STOP SO THAT THE BUMPER WILL COME IN CONTACT WITH THE FLOOR BAR 2-3/16" 1-3/16" PULL SIDE BUMPER DISTANCE APPROX. DETERMINED BY CUSTOMER -DISTANCE ~5-1/2" FRONT VIEW TOP VIEW DOOR Installing Pipe Stop in Cement Floor Determine location of pipe stop in floor. NOTE: WHEN POSSIBLE INSTALL WELL OUT OF FOOT TRAFFIC DOOR HOOK ROTATES Drill 1-1/4" wide hole in concrete floor. Depth is OUT OF THE WAY WHEN determined by the amount of pipe remaining above the NOT IN USE finished floor. Once drilled, fill the drilled hole with Wet Quick-Dry Cement approximately 60% full. DISTANCE DETERMINED Push Pipe stop into wet cement all the way down, BY CUSTOMER removing any excess cement that has pushed up from the hole. Verify the pipe stop is centered in the cement. Ø1" Let Dry completely before use. Cement drying time will vary on quick-dry cement instructions. 11" Installing Door Bracket Assembly Door Bracket should be located near the lock edge of the door. Horizontal and vertical location will be determined by the location of the pipe stop installed. Door Bracket should be installed so that the bumper will Δ come in contact with the pipe stop.

Once location is determined use the provided fasteners to install into the door.

PATENTED

www.abhmfg.com

E-mail: abhinfo@abhmfg.com Architectural Builders Hardware Mfg., Inc. 1222 Ardmore Ave., Itasca, IL 60143 630.875.9900; FAX 800.9FAXABH (932.9224)

QUICK DRY

CEMENT

1804-04.DWG

1804 PAGE 1 OF 1

SIDE VIEW

CONCRETE

FLOOR
