0173 Template – 3by4 Offset Top and Bottom Pivot Set

0173 PIVOT SET, 3/4" OFFSET, HANDED 0173 BOTTOM PIVOT 0180 TOP PIVOT 7-1/4" 6-3/4" 3-55/64" 2-45/64" 1/8" Min CLEARANCE 1-35/64 3/4 1/4-20 x 3/4" FHMS or 25/64 23/64" 1/2" 45/64' #14 x 1-1/2" FHWS R3/16" 1/8" MIN. CLEARANCE BETWEEN DOOR AND STOP 3/4" (3 PLACES) .IAMR 13/16" R3/16' (<del>(</del> (<del>-</del>) R3/4 (<u>(</u> BEVEL EDGE OF DOOR 1/8" IN 2" (B) R1/8" 3/4' 1-7/8" 1/4-20 x 3/4" FHMS or 3/4' #14 x 1-1/2" FHWS (4 PLACES) 7/16 3/4' SEE VIEW R3/8' 13/16" "A" 1/4' 3/4 1/16" -1. PIVOTS DRILLED FOR 1/4-20 FHMS OR #14 FHWS 2. REINFORCING BY OTHERS. 3. IT IS THE DOOR AND FRAME MANUFACTURERS RESPONSIBILITY TO CHECK THE HARDWARE SCHEDULE AND PREP THE DOORS AND FRAMES. 3/4' 4. MAXIMUM DEGREE OF OPENING, 180°, TRIM PREMITTING 5. RIGHT HANDED SHOWN. DOOR MORTISE "A" DEPTH FOR ARM "A" VIEW "A" 1/4" THRESHOLD 3/4" 11/16' 1/2" THRESHOLD 7/16' 3/16' 15/16 3/4 THRESHOLD FI OOR WITH THRESHOLD 3/16' 1-5/8 INSTALLATION INSTRUCTIONS FROM FACE OF DOOR DOOR STOP 1. MEASURE 13/16" OUT FROM DOOR JAMB TO DOOR STOP 2. ALLOW $\backslash frac\{1\}\{8\}$ " MIN CLEARANCE FROM DOOR STOP TO DOOR BEVEL DOOF 1/8" IN 2' FACE. MEASURE DOOR THICKNESS AND ADD 3/4". RIGHT HANDED DOOR DOOR JAMB 3. WHERE THESE LINES INTERSECT DETERMINES THE CENTERLINE OF THE PIVOT POINT. 4. DRILL HOLE IN FLOOR LINE. INSERT PIVOT STUD SO THAT IT IS 13/16" FROM -3/4" FROM FACE OF DOOR TO CENTERLINE OF PIVOT POSITIONED PER DRAWING BELOW FACE OF JAMB 5. INSTALL 0180 DOOR PORTION PER TEMPLATE TO CENTERLINE PIVOT STUD POSITION 6. INSTALL 0180 JAMB PORTION PER TEMPLATE. 7. INSTALL 0173 DOOR PORTION PER TEMPLATE. (1) 8. IF 019 INTERMEDIATE PIVOT IS USED, SEE SEPARATE TEMPLATE. 9. SET DOOR ON 0173 FLOOR STUD. 10. PUSH 0180 PIVOT PIN IN PLACE AND SECURELY TIGHTEN 0180 END CAP. 11. PUT 0173 ARM COVER ON AND SECURE TIGHTLY WITH 0173 COVER SCREW. (3) 4 CENTERLINE OF TOP PIVOT MUST 3/4" FINISHED LINE UP WITH 1 173 COVER SCREW CENTERLINE OF 173 ARM COVER 0180 END CAP 0180 JAMB PORTION PIVOT ARM. 173 DOOR PORTION 0180 NEEDLE BEARING 0173 FLOOR STUD

Disclaimer: This template is to be used for installation, as shown, of said product and is not suitable for every application method. Custom applications, where door sizes, weights and conflicting hardware are a factor, need to be addressed with ABH and proper instructions provided. ABH is not liable for failure or performance of the product due to improper installation methods and/or use. Improper use and/or installation of this product will void the standard warranty.
